English 5
HEATING
D
B: Dry bulb temperature (°C)
WB: Wet bulb temperature (°C)
The setting temperature range of the remote con-
troller is 16°C to 32°C.
Regarding places for installation
• Is the air conditioner installed at a well-venti-
lated place where there are no obstacles
around?
• Do not use the air conditioner in the following
places.
a. Filled with much mineral oil such as cutting oil
b. Where there is much salt such as a beach area
c. Where sulfured gas exists such as a hot-spring
resort
d. Where there are considerable voltage fluctua-
tions such as a factory or plant
e. Vehicles and vessels
f
. Where there is much spray of oil and vapor
such as a cookery, etc.
g. Where there are machines generating electro-
magnetic waves
h. Filled with acid and/or alkaline steam or vapor
• Is a snow protection measure taken?
For details, consult your dealer.
OUTDOOR
UNIT
INDOOR
TEMPERA-
TURE
OUTDOOR
TEMPERATURE
RXS35 · 50 · 60 DB 10 to 30
DB – 14 to 24
WB – 15 to 18
3MXS52 · 68
4MXS68 · 80
5MXS90
DB 10 to 30
DB
– 14 to 21
WB – 15 to 15.5
RQ71 · 100 · 125 DB 10 to 27
DB – 9 to 21
WB – 10 to 15
REQ71 · 100 · 125
DB 10 to 27
DB – 9 to 21
WB – 10 to 15
RZQ71 · 100 ·
125 · 140
DB 10 to 27
DB – 19.5 to 21
WB – 20 to 15.5
RZQS71 · 100 ·
125 · 140
DB 10 to 27
DB – 14 to 21
WB – 15 to 15.5
RZQ200
· 250
DB 10 to 27
DB – 14 to 21
WB – 15 to 15
RZQG DB 10 to 27
DB –19.5 to 21
WB –20 to 15.5
RZQSG71 DB 10 to 30
DB – 14 to 21
WB –15 to 15.5
RZQSG100 ·
125 · 140
DB 10 to 28
DB – 14 to 21
WB –15 to 15.5
4. INSTALLATION SITE
Regarding wiring
• All wiring must be performed by an authorized
electrician.
To do wiring, ask your dealer. Never do it by your-
self.
• Make sure that a separate power supply circuit
is provided for this air conditioner and that all
electrical work is carried out by qualified per-
sonnel according to local laws and regulations.
Pay attention to running noises, too
• Are the following places selected?
a. A place that can sufficiently withstand the
weight of the air conditioner with less running
noises and vibrations.
b. A place where the hot wind discharged from the
air outlet of the outdoor unit and the running
noises.
• Are you sure that there are no obstacles near
the air outlet of the outdoor unit?
Such obstacles may result in declined perfor-
mance and increased running noises.
• If abnormal noises occur in use, stop the
operation of the air conditioner, and then con-
sult your dealer or our service station.
Regarding drainage of drain piping
• Is the drain piping executed to perform com-
plete drainage?
If proper drainage is not carried out from the out-
door drain pipes during air-conditioning operation,
chances are that dust and dirt are clogged in the
pipe. This may result in a water leakage from the
indoor unit. Under such circumstances, stop the
operation of the air conditioner, and then consult
your dealer or our service station.
Refer to figure 1 on page [1]
5.
NAME AND FUNCTION OF EACH
SWITCH
AND DISPLAY ON THE
REMOTE CONTROLLER
1
ON/OFF BUTTON
Press the button and the system will start.
Press the button again and the system will
stop.
2
OPERATION LAMP (RED)
The lamp lights up during operation.
3
DISPLAY “ ”
(UNDER CENTRALIZED CONTROL)
When this display shows, the system is
UNDER CENTRALIZED CONTROL.
01_EN_3P303408-1C.fm Page 5 Tuesday, January 10, 2012 8:01 PM
