FHYCP + FCQ
Split System air conditioners
4PW23696-1
Installation manual
9
WIRING DIAGRAM
33H......................FLOAT SWITCH
A1P......................PRINTED CIRCUIT BOARD
C1R .....................CAPACITOR (FAN MOTOR)
CD .......................CURRENT DETECT CIRCUIT
F1U......................FUSE (250 V/5 A)
(only for
FCQ35~60
)
HAP,HBP .............LIGHT EMITTING DIODE (SERVICE MONITOR -
GREEN)
M1A .....................MOTOR (SWING FLAP)
M2F .....................MOTOR (INDOOR FAN)
M3P .....................MOTOR (DRAIN PUMP)
PC........................PHASE CONTROL CIRCUIT
Q1F......................THERMO SWITCH (M2F EMBEDDED)
R1T......................THERMISTOR (AIR)
R2T......................THERMISTOR (LIQUID)
R3T......................THERMISTOR (COIL) (only for FCQ35~60)
RC .......................SIGNAL RECEIVER CIRCUIT
RyC......................MAGNETIC RELAY (OUTDOOR UNIT
COMPRESSOR)
RyP......................MAGNETIC RELAY (DRAIN PUMP)
SS1......................SELECTOR SWITCH (EMERGENCY)
T1R......................TRANSFORMER (230 V, 22 V)
TC........................SIGNAL TRANMISSION CIRCUIT
X1M,X2M.............TERMINAL STRIP
WIRED REMOTE CONTROLLER
SS1 ..................... SELECTOR SWITCH (MAIN/SUB)
RECEIVER/DISPLAY UNIT (ATTACHED TO WIRELESS REMOTE
CONTROLLER)
A2P,A3P .............. PRINTED CIRCUIT BOARD
BS ....................... ON/OFF BUTTON
H1P..................... LIGHT EMITTING DIODE (ON - RED)
H2P..................... LIGHT EMITTING DIODE (TIMER - GREEN)
H3P..................... LIGHT EMITTING DIODE (FILTER SIGN - RED)
H4P..................... LIGHT EMITTING DIODE (DEFROST - ORANGE)
SS1 ..................... SELECTOR SWITCH (MAIN/SUB)
SS2 ..................... SELECTOR SWITCH (WIRELESS ADDRESS
SET)
ADAPTER FOR WIRING
RyC,RyF ............. MAGNETIC RELAY
CONNECTOR FOR OPTIONAL PARTS
X30A ................... CONNECTOR (INTERFACE ADAPTOR FOR
SKY AIR SERIES) (only for FHYCP)
X33A ................... CONNECTOR (ADAPTOR FOR WIRING)
X35A ................... CONNECTOR (GROUP CONTROL ADAPTOR)
X40A ................... CONNECTOR (REMOTE ON/OFF, FORCED
OFF)
X60A,X61A ......... CONNECTOR (INTERFACE ADAPTOR FOR
SKY AIR SERIES) (only for FCQ)
: FIELD WIRING BLK : BLACK
: TERMINAL RED : RED
: CONNECTOR WHT : WHITE
: WIRE CLAMP YLW : YELLOW
: PROTECTIVE EARTH (SCREW)
,
RECEIVER/DISPLAY UNIT :
IN CASE OF SIMULTANEOUS OPERATION SYSTEM :
MASTER :
SLAVE :
REMOTE CONTROLLER :
WIRED REMOTE CONTROLLER :
ADAPTOR FOR WIRING :
TERMINALS FOR OPERATION INDICATOR :
FAN OPERATION :
COMPRESSOR OPERATION :
SWITCH BOX :
NOTE
1. WHEN USING THE CENTRAL REMOTE CONTROLLER, SEE MANUAL FOR CONNECTION TO UNIT.
2. X24A IS CONNECTED WHEN THE WIRELESS REMOTE CONTROLLER KIT IS USED.
3. THE REMOTE CONTROLLER MODEL VARIES ACCORDING TO THE COMBINATION SYSTEM. SEE TECHNICAL MATERIALS
AND CATALOGS, ETC. BEFORE CONNECTING.
