Si041257EC
Removal Procedure 1
Table of Contents
1. Air Filters / Front Panel / Horizontal Blade / Vertical Blade ASSYs ........2
2. Front Grille ..............................................................................................5
3. Electrical Box ..........................................................................................6
4. PCBs / Swing Motor ................................................................................8
5. Indoor Heat Exchanger .........................................................................10
6. Fan Motor / Fan Rotor...........................................................................12
Note:
The illustrations may be slightly different depending on the model.
