6 Split Type Air Conditioners FTK(X)S-L Series
3. Specifications
3.1 Cooling Only
50 Hz, 220 - 230 - 240 V / 60 Hz, 220 - 230 V
Note:

The data are based on the conditions shown in the table below.
Model
Indoor Unit FTKS20LVMA FTKS25LVMA
Outdoor Unit RKS20LVMA RKS25LVMA
Capacity
Rated (Min. ~ Max.)
kW 2.0 (1.3 ~ 2.8) 2.5 (1.3 ~ 3.2)
Btu/h 6,800 (4,400 ~ 9,600) 8,500 (4,400 ~ 10,900)
kcal/h 1,720 (1,120 ~ 2,410) 2,150 (1,120 ~ 2,750)
Moisture Removal L/h 0.9 1.2
Running Current (Rated) A 2.6 - 2.5 - 2.4 / 2.6 - 2.5 3.1 - 3.0 - 2.9 / 3.1 - 3.0
Power Consumption
Rated (Min. ~ Max.)
W 450 (320 ~ 910) 540 (320 ~ 770)
Power Factor % 78.7 - 78.3 - 78.1 / 78.7 - 78.3 79.2 - 78.3 - 77.6 / 79.2 - 78.3
EER (Cooling)
Rated (Min. ~ Max.)
W/W 4.44 (4.06 ~ 3.08) 4.63 (4.06 ~ 4.16)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 9.5 φ 9.5
Drain mm φ 16.0 φ 16.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 20 20
Max. Interunit Height Difference m 15 15
Chargeless m 10 10
Amount of Additional Charge of Refrigerant g/m 20 20
Indoor Unit FTKS20LVMA FTKS25LVMA
Front Panel Colour White White
Airflow Rate
H
m³/min
(cfm)
9.7 (343) 10.6 (374)
M 7.7 (272) 8.1 (286)
L 5.6 (198) 5.7 (201)
SL 4.1 (145) 4.4 (155)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downwards Right, Left, Horizontal, Downwards
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.09 - 0.08 - 0.08 / 0.09 - 0.08 0.10 - 0.09 - 0.09 / 0.10 - 0.09
Power Consumption (Rated) W 18 - 18 - 18 / 18 - 18 20 - 20 - 20 / 20 - 20
Power Factor % 90.9 - 97.8 - 93.8 / 90.9 - 97.8 90.9 - 96.6 - 92.6 / 90.9 - 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 274 × 870 × 366 274 × 870 × 366
Weight (Mass) kg 9 10
Gross Weight (Gross Mass) kg 13 13
Sound Pressure
Level
H / M / L / SL dB(A) 38 / 32 / 25 / 22 40 / 32 / 25 / 22
Sound Power
Level
HdB 54 56
Outdoor Unit RKS20LVMA RKS25LVMA
Casing Colour Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AEXD 1YC23AEXD
Motor Output W 600 600
Refrigerant Oil
Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant
Type R-410A R-410A
Charge kg 0.8 1.2
Airflow Rate
H
m³/min
(cfm)
36.2 (1,278) 33.5 (1,183)
SL 32.7 (1,155) 30.1 (1,063)
Fan
Type Propeller Propeller
Motor Output W 33 33
Running Current (Rated) A 2.5 - 2.4 - 2.3 / 2.5 - 2.4 3.0 - 2.9 - 2.8 / 3.0 - 2.9
Power Consumption (Rated) W 432 - 432 - 432 / 432 - 432 520 - 520 - 520 / 520 - 520
Power Factor % 78.5 - 78.3 - 78.3 / 78.5 - 78.3 78.8 - 78.0 - 77.4 / 78.8 - 78.0
Starting Current A 2.6 3.1
Dimensions (H × W × D) mm 550 × 765 × 285 550 × 765 × 285
Packaged Dimensions (H × W × D) mm 589 × 882 × 363 589 × 882 × 363
Weight (Mass) kg 31 34
Gross Weight (Gross Mass) kg 35 38
Sound Pressure
Level
H / SL dB(A) 46 / 43 47 / 43
Sound Power
Level
HdB 60 61
Drawing No. 3D075852 3D075853
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB
7.5 m
