• Split Sky Air • Indoor Units 2
• Indoor Units • R-410A • FUQ-BVV1B
2 Specifications
2-1 FOR INDOOR UNITS ONLY
FUQ71 BVV1B FUQ1 00BVV1B FUQ12 5BVV1B
Nominal Input Cooling kW 0.180 0.289 0.289
Heating kW 0.160 0.269 0.269
2-2 TECHNICAL SPECIFICATIONS
FUQ71 BVV1B FUQ1 00BVV1B FUQ12 5BVV1B
Casing Colour White
Material Resin
Dimensions Packing Height mm 230 295 295
Width mm 960 960 960
Depth mm 960 960 960
Unit Height mm 165 230 230
Width mm 895 895 895
Depth mm 895 895 895
Weight Unit kg 25.0 31.0 31.0
Packed Unit kg 31.0 38.0 38.0
Heat
Exchanger
Dimensions Length mm 2101 2101 2101
Nr of Rows 3 3 3
Fin Pitch mm 1.50 1.50 1.50
Nr of Passes 8 8 12
Face
Area
m² 0.265 0.353 0.353
Nr of Stages 6 8 8
Empty Tubeplate
Hole
4
Tube type N-Hix
Fin Type Cross fin coil (Multi louver fins and N-hix tubes)
Fan Type Turbo fan
Quantity 1 1 1
Air Flow Rate Cooling High m³/min 19.0 29.0 32.0
Low m³/min 14.0 21.0 23.0
Heating High m³/min 19.0 29.0 32.0
Low m³/min 14.0 21.0 23.0
Fan Motor Quantity 1 1 1
Model QTS48A10M QTS50B15M QTS50B15M
Number of steps 2 2 2
Output
(high)
W 45 90 90
Cooling Sound Power High dBA 56.0 59.0 60.0
Low dBA 51.0 54.0 55.0
Sound
Pressure
High dBA 40.0 43.0 44.0
Low dBA 35.0 38.0 39.0
Heating Sound Power High dBA 56.0 59.0 60.0
Low dBA 51.0 54.0 55.0
Sound
Pressure
High dBA 40.0 43.0 44.0
Low dBA 35.0 38.0 39.0
Refrigerant Type R-410A
Piping
connections
Liquid (OD) Type Flare connection
Diameter
(OD)
mm 9.5 9.5 9.5
Gas Type Flare connection
Diameter
(OD)
mm 15.9 15.9 15.9
Drain Diameter
(OD)
mm I.D. 20/O.D. 26
Heat Insulation Heat resistant foamed polyethylene, regular foamed polyethylene
Air Filter Resin net with mold resistance
Safety Devices Fan motor thermal protector
