Daikin FWE07E - Sound Power Levels

27
Sound Data
Model Speed
1/1 Octave Sound Pressure Level (dB, reference 20mPa)
Overall
(dBA)
Noise
Criteria
125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz
FWC02FD
High 41 37 38 38 30 23 13 40 37
Med 43 36 37 37 28 21 12 39 36
Low 39 35 34 33 24 16 5 36 32
FWC03FD
High 41 41 39 35 32 26 18 40 34
Med 41 40 38 35 31 25 17 39 34
Low 41 38 37 34 29 23 15 37 33
FWC04FD
High 43 41 40 37 33 26 18 41 36
Med 45 41 39 36 32 25 16 40 35
Low 45 38 36 33 28 20 9 37 32
FWC05FD
High 44 42 43 38 34 29 20 42 38
Med 43 42 42 38 34 28 20 41 37
Low 41 40 40 36 31 25 15 39 35
FWC06FD
High 45 44 44 41 34 28 21 45 40
Med 46 44 44 41 34 28 20 44 40
Low 45 42 42 38 31 26 16 41 37
FWC08FD
High 52 49 46 47 36 28 21 47 46
Med 51 47 46 46 35 27 20 46 45
Low 50 43 44 45 33 25 17 45 44
FWC10FD
High 51 47 46 45 39 32 23 48 44
Med 51 48 46 44 38 31 22 47 44
Low 49 45 44 43 36 29 19 45 42
Microphone position: 1.5m below the centre of the unit.
(Tested with 2m length duct at the air discharge outlet and 1m length of air return duct).
Model
(LSP)
Speed
1/1 Octave Sound Pressure Level (dB, reference 20mPa)
Overall
(dBA)
Noise
Criteria
125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz
FWC02G
High 41 33 29 25 17 10 9 31 23
Med 35 28 24 19 9 8 8 26 0
Low 29 23 18 12 8 8 7 20 0
FWC03G
High 36 34 29 28 18 11 9 32 26
Med 28 27 23 19 9 8 8 25 0
Low 26 20 16 15 8 8 8 20 0
FWC04G
High 40 36 32 30 23 16 9 35 29
Med 35 31 27 25 16 9 8 29 23
Low 27 24 19 13 9 9 8 21 0
FWC06G
High 45 40 35 32 28 22 13 38 31
Med 43 36 32 29 25 19 11 35 28
Low 40 30 28 25 18 10 8 30 23
FWC08G
High 45 41 37 33 28 20 12 39 32
Med 41 37 32 27 21 12 11 34 26
Low 35 29 25 18 11 10 10 26 0
FWC10G
High 47 44 38 35 30 22 16 41 34
Med 45 39 35 30 24 15 9 37 30
Low 44 33 27 22 15 8 8 31 25
FWC12G
High 47 43 40 37 32 23 15 42 36
Med 44 40 37 34 28 19 9 39 33
Low 41 36 33 30 23 12 8 35 29
Microphone position: 1.5m below the centre of the unit.
(Tested with 2m length duct at the air discharge outlet and 1m length of air return duct).
