EDUS391000-F1 Specifications
FXFQ-P 3
Ceiling Mounted Cassette Type (Round Flow)
Notes:
 1 Nominal cooling capacities are based on the following conditions:
Return air temperature: 80°FDB(27°CDB), 67°FWB(19.4°CWB)
Outdoor temperature: 95°FDB (35°CDB)
Equivalent ref. piping length: 25ft (7.5 m)(Horizontal)
 2 Nominal heating capacities are based on the following conditions:
Return air temperature: 70°FDB(21°CDB).
Outdoor temperature: 47°FDB (8.3°CDB ), 43°FWB (6°CWB)
Equivalent ref. piping length: 25ft (7.5 m) (Horizontal)
 3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
4 Refer to page 9 for Power Input.
 5 Sound levels are measured under JIS conditions.
Model FXFQ30PVJU FXFQ36PVJU FXFQ48PVJU
1

, 3

Cooling Capacity Btu/h 30,000 36,000 48,000
2

, 3

Heating Capacity Btu/h 34,000 40,000 54,000
Casing / Color Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) in. (mm)
9-11/16 × 33-1/16 × 33-1/16
(246 x 840 x 840)
11-5/16×33-1/16×33-1/16
(287 x 840 x 840)
1 1 - 5 / 1 6 × 3 3 - 1 / 1 6 × 3 3 - 1 / 1 6
(287 x 840 x 840)
Coil (Cross
Fin Coil)
Rows×Stages×FPI 2×10×21 2×12×21 2×12×21
Face Area ft² (m
2
) 4.80 (1.46) 5.76 (1.8) 5.76 (1.8)
Fan
Model QTS48C15M QTS48C15M QTS48C15M
Type Turbo Fan Turbo Fan Turbo Fan
Motor Output W 56 120 120
Air Flow Rate (HH/H/L) cfm 830/670/530 1180/910/700 1220/970/790
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Sound Absorbing Thermal Insulation Material Polyurethane Form Polyurethane Form Polyurethane Form
Weight Lbs (kg 48.5 (22) 55 (25) 55 (25)
5

Sound Level (HH/H/L) dBA 38/35/31 44/38/32 45/40/34
Piping
Connections
Liquid Pipes in. (mm) φ3/8 (9.5) (Flare Connection) φ3/8 (9.5) (Flare Connection) φ3/8 (9.5) (Flare Connection)
Gas Pipes in. (mm) φ5/8 (15.8) (Flare Connection) φ5/8 (15.8) (Flare Connection) φ5/8 (15.8) (Flare Connection)
Drain Pipe in. (mm)
VP25
External Dia. 1-1/4 (31.8)
Internal Dia. 1(25.4)
VP25
External Dia. 1-1/4 (31.8)
Internal Dia. 1(25.4)
VP25
External 1-1/4 (31.8)
Internal Dia. 1 (25.4)
Safety Devices Fuse Fuse Fuse
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit R-410A VRV Series R-410A VRV Series R-410A VRV Series
Standard Accessories
Operation Manual. Installation Manual.
Paper Pattern for Installation. Drain
Hose. Sealing Pads. Clamps. Washers.
Screws. Insulation for Fitting. Clamp
Metal.
Operation Manual. Installation Manual.
Paper Pattern for Installation. Drain
Hose. Sealing Pads. Clamps. Washers.
Screws. Insulation for Fitting. Clamp
Metal.
Operation Manual. Installation Manual.
Paper Pattern for Installation. Drain
Hose. Sealing Pads. Clamps.
Washers. Screws. Insulation for Fitting.
Clamp Metal.
Decoration
Panels
(Option)
Model BYCP125K-W1 BYCP125K-W1 BYCP125K-W1
Color Fresh White Fresh White Fresh White
Dimensions: (H×W×D) in. (mm)
2 × 3 7 - 3 / 8 × 3 7 - 3 / 8
(51 x 949 x 949)
2 × 3 7 - 3 / 8 × 3 7 - 3 / 8
(51 x 949 x 949)
2 × 3 7 - 3 / 8 × 3 7 - 3 / 8
(51 x 949 x 949)
Air Filter
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Weight Lbs (kg 12.2 (5.5) 12.2 (5.5) 12.2 (5.5)
Drawing No. C: 3D070521
(
)
(
)
(
)
