• VRV Systems • Indoor Unit
3
• Indoor Unit • Ceiling suspended unit • FXHQ-A
2 Specifications
Standard Accessories : Screw for wiring fixture;
Standard Accessories : Wiring fixture;
Standard Accessories : Resin bushing;
Standard Accessories : Installation pattern;
Standard Accessories : Sealing material;
Standard Accessories : Joint insulating material;
Standard Accessories : Clamps;
Standard Accessories : Washer for hanger bracket;
Standard Accessories : Clamp metal;
Standard Accessories : Drain hose;
2-1 Technical Specifications FXHQ32A FXHQ63A FXHQ100A
Cooling capacity Nom. kW 3.6 7.1 11.2
Heating capacity Nom. kW 4.0 8.0 12.5
Power input - 50Hz Cooling Nom. kW 0.107 0.111 0.237
Heating Nom. kW 0.107 0.111 0.237
Casing Colour Fresh White
Material Resin
Dimensions Unit Height mm 235
Width mm 960 1,270 1,590
Depth mm 690
Packed unit Height mm 340 349
Width mm 1,116 1,426 1,746
Depth mm 858 878
Weight Unit kg 24 33 39
Packed unit kg 38 55 62
Heat exchanger Type Cross fin coil (multi louver fins and Hi-XSL tubes)
Length mm 722 1,032 1,352
Rows Quantity 2 3
Fin pitch mm 1.5
Passes Quantity 4 5 10
Face area m² 0.213 0.303 0.398
Stages Quantity 14
Empty tubeplate
hole
Quantity 0
Fan Type Sirocco fan
Quantity 2 3 4
Air flow rate - 50Hz Cooling High m³/min 14.0 20.0 29.5
Nom. m³/min 12.0 17.0 24.0
Low m³/min 10.0 14.0 19.0
Heating High m³/min 14.0 20.0 29.5
Nom. m³/min 12.0 17.0 24.0
Low m³/min 10.0 14.0 19.0
Fan motor Model 2D15L1AA1 3D15L1AA1 4D15L1AC1
Speed Steps 3
Output High W 60 91 150
Sound pressure level Cooling High dBA 36.0 37.0 44.0
Nom. dBA 34.0 35.0 37.0
Low dBA 31.0 34.0
Heating High dBA 36.0 37.0 44.0
Nom. dBA 34.0 35.0 37.0
Low dBA 31.0 34.0
Refrigerant Type R-410A
Piping connections Liquid Type Flare connection
OD mm 6.35 9.52
Gas Type Flare connection
OD mm 12.7 15.9
Drain VP20 (I.D. 20/O.D. 26)
Heat insulation Heat resistant foamed polyethylene, regular foamed polyethylene
Air filter Type Resin net with mold resistance
