Daikin FXHQ-MAVE Series User Manual

• Indoor Units • Ceiling Suspended Unit • FXHQ-MAVE
•VRV
®
Systems • Indoor Units
4
1 Specifications
3
1
1
1-2 ELECTRICAL SPECIFICATIONS (50HZ) FXHQ32MAVE FXHQ63MAVE FXHQ100MAVE
Power Supply Name VE
Phase 1~
Frequency Hz 50
Voltage V 220-240
Current Minimum circuit amps (MCA) A 0.8 0.8 0.9
Maximum fuse amps (MFA) A 15 15 15
Full load amps (FLA) A 0.6 0.6 0.7
Voltage range Minimum V -10%
Maximum V +10%
Notes Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminals
is not below or above listed range limits.
Maximum allowable voltage range variation between phases is 2%.
MCA/MFA : MCA = 1.25 x FLA
MFA is smaller than or equal to 4 x FLA
Next lower standard fuse rating minimum 15A
Select wire size based on the MCA
Instead of a fuse, use a circuit breaker
1-3 ELECTRICAL SPECIFICATIONS (60HZ) FXHQ32MAVE FXHQ63MAVE FXHQ100MAVE
Power Supply Name VE
Phase 1~
Frequency Hz 60
Voltage V 220
Current Minimum circuit amps (MCA) A 0.9 0.9 1.3
Maximum fuse amps (MFA) A 15 15 15
Full load amps (FLA) A 0.7 0.7 1.0
Voltage range Minimum V -10%
Maximum V +10%
Notes Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminals
is not below or above listed range limits.
Maximum allowable voltage range variation between phases is 2%.
MCA/MFA : MCA = 1.25 x FLA
MFA is smaller than or equal to 4 x FLA
Next lower standard fuse rating minimum 15A
Select wire size based on the MCA
Instead of a fuse, use a circuit breaker

Daikin FXHQ-MAVE Series Specifications

General

Brand	Daikin
Model	FXHQ-MAVE Series
Category	Air Conditioner
Language	English
