25 English
10-1 SETTING OF CEILING HEIGHT
• Set the SECOND CODE No. according to the ceiling height as shown in the Table 3.
(The SECOND CODE No. is set at “01”, when shipping from the factory.)
Table 3
NOTE
Do not set the SECOND CODE No. “03”.
10-2 SETTING WHEN AN OPTIONAL ACCESSORY IS ATTACHED
•
For setting when attaching an optional accessory, refer to the installation manual attached to the optional accessory.
10-3 WHEN USING WIRELESS REMOTE CONTROLLER
• When using a wireless remote controller, it is necessary to set the wireless remote controller address. Refer
to the installation manual attached to the wireless remote controller.
10-4 SETTING FAN SPEED DURING THERMOSTAT OFF
• Set the fan speed according to the using environment after consultation with your customer.
(When shipping, the SECOND CODE No. “02” is set for the fan speed during the cooler thermostat OFF,
and other are set at “01”.)
Table 4
10-5 SETTING FILTER SIGN
• A message to inform the air filter cleaning time will be indicated on the remote controller.
•
Set the SECOND CODE No. to the number shown in the Table 5 according to the amount of dust or pollution
in the room.
• Though the indoor unit is equipped with the long life filter, it is necessary to periodically clean the filter to
avoid clogging of the filter. Please also explain the set time to the customer.
• The periodical filter cleaning time can be shortened depending on the environment.
Table 5
* Use “No indication” setting when cleaning indication is not necessary such as the case of periodical clean-
ing being carried out.
Ceiling height (m)
Mode No.
FIRST CODE
No.
SECOND
CODE No.
Type 32 Type 63 Type 100
Standard 2.7 or less 2.7 or less 3.8 or less
13 (23) 0
01
High ceiling 2.7-3.5 2.7-3.5 3.8-4.3 02
Setting Mode No. FIRST CODE No. SECOND CODE No.
Fan operates/stops during
thermo OFF (Cooling · heating)
Operates
11 (21) 2
01
Stops 02
Fan speed during cooling ther-
mostat OFF
LL (Extra low)
12 (22) 6
01
Setting 02
Fan speed during heating ther-
mostat OFF
LL (Extra low)
12 (22) 3
01
Setting 02
Contamination
Filter hours
(long life type)
Mode No.
FIRST CODE
No.
SECOND
CODE No.
Normal Approx. 2500 hrs
10 (20)
0
01
More contaminated Approx. 1250 hrs 02
With indication
3
01
No indication* 02
01_EN_3P249378-8N.fm Page 25 Saturday, September 29, 2012 3:02 PM
