27 English
3D079560-1 FXHQ32 • 63 • 100AVEB
A1P
C105
F1U
HAP
KPR
M1F
M1S
PS
R1T
R2T
R3T
V1R
X1M
X2M
Y1E
Z1F
X15A
X24A
X25A
X33A
X35A
WIRED REMOTE CONTROLLER
THERMISTOR (AIR)
PRINTED CIRCUIT BOARD
CAPACITOR
FUSE (T, 3.15A, 250V)
FLASHING LAMP
(SERVICE MONITOR GREEN)
MAGNETIC RELAY (DRAIN
PUMP)
MOTOR (INDOOR FAN)
MOTOR (SWING BLADE)
POWER SUPPLY CIRCUIT
THERMISTOR (AIR)
THERMISTOR (COIL)
THERMISTOR (COIL)
DIODE BRIDGE
TERMINAL BLOCK
TERMINAL BLOCK
ELECTRONIC
EXPANSION VALVE
NOISE FILTER
CONNECTOR
(FLOAT SWITCH)
CONNECTOR
(WIRELESS REMOTE
CONTROLLER)
CONNECTOR (DRAIN PUMP)
CONNECTOR
(ADAPTOR FOR WIRING)
CONNECTOR
(POWER SUPPLY FOR
ADAPTOR)
R1T
PRINTED CIRCUIT BOARD
PRINTED CIRCUIT BOARD
PUSH BUTTON (ON/OFF)
PILOT LAMP (ON-RED)
PILOT LAMP
(TIMER-GREEN)
PILOT LAMP
(FILTER SIGN-RED)
PILOT LAMP
(DEFROST-ORANGE)
SELECTOR SWITCH
(MAIN/SUB)
SELECTOR SWITCH
(WIRELESS ADDRESS SET)
A2P
A3P
BS1
H1P
H2P
H3P
H4P
SS1
SS2
WIRING DIAGRAM
CONNECTOR FOR OPTIONAL PARTS
INDOOR UNIT
2. IN CASE USING CENTRAL REMOTE CONTROLLER, CONNECT IT TO THE UNIT IN ACCORDANCE WITH THE ATTACHED
INSTALLATION MANUAL.
3. X15A, X25A ARE CONNECTED WHEN THE DRAIN UP KIT IS BEING USED.
IN ACCORDANCE WITH THE ATTACHED INSTALLATION MANUAL.
4. IN CASE OF MAIN/SUB CHANGEOVER.
SEE THE INSTALLATION MANUAL ATTACHED TO REMOTE CONTROLLER.
5. SYMBOLS SHOW AS FOLLOWS: BLK: BLACK RED: RED BLU: BLUE WHT: WHITE YLW: YELLOW GRN: GREEN
ORG: ORANGE BRN: BROWN.
6. SHOWS ONLY IN CASE OF PROTECTED PIPES. USE H07RN-F IN CASE OF NO PROTECTION.
7. WHEN CONNECTING THE INPUT WIRES FROM OUTSIDE, FORCED OFF OR ON/OFF CONTROL OPERATION CAN BE
SELECTED BY THE REMOTE CONTROLLER. SEE INSTALLATION MANUAL FOR MORE DETAILS.
: TERMINAL BLOCK : CONNECTOR : FIELD WIRING
: SHORT CIRCUIT CONNECTOR
1.
NOTES
3
5
6
4
1
2
2
7
8
WIRELESS REMOTE CONTROLLER
(RECEIVER / DISPLAY UNIT)
Fig. 36
01_EN_3P249378-8N.fm Page 27 Saturday, September 29, 2012 3:02 PM
