Daikin RF60RRV161 - Page 8

Electrical Component ASSY Si011360EC
6 Removal Procedure
5
6
Remove the 2 screws
on the right side
(lower).
Remove the 3 screws
on the rear side.
7 Unfasten the hook on
the back.

When reassembling, make
sure the hook is securely
fastened.
8 Remove the right side
panel.

The right side panel has 2
hooks at the bottom.
Step Procedure Points
(R18995)
Hook
(R23467)
(R19490)
Right side panel
Hook
(R23468)
