Si011360EC Electrical Component ASSY
Removal Procedure 7
2. Remove the electrical
component ASSY.

Capacitor (C1)
Pattern 1:
Pattern 2:
1
2
Pull out all the 3
remaining terminals
from the capacitor (C1).
Pull out the terminal
3 (back, white) from the
terminal board (X1M).
* When reassembling, connect the connectors as
below.
Terminal board (X1M)
Capacitor (C1)
Pattern 1: RC50PRV16, RQ60PRV16
Step Procedure Points
Capacitor
Terminal board
(R20992)
from compressor(R): blue
from compressor(S):
red
(R23477)
from terminal board
2(back): blue
from compressor(R): blue
from compressor(S):
red
from terminal board
2(back): blue
(R23469)
from compressor(C):
white
(R23470)
from
earth/ground
terminal:
yellow/green
from capacitor(C1):
blue
from fan motor:
black
from fan motor:
red
from fan motor:
white
from compressor(R):
blue
from compressor(S):
red
from terminal board 2:
blue
(R23471)
