56
TM-FLH-0515-C
Figure D
Ceiling Board
Top Panel Of Unit
10mm or more
300mm or more
300mm or more
10mm or more
10mm
10mm
10mm
166mm
Semi-Enclose Mounting
In case the unit is to be half-recessed into a false ceiling, please check that the unit is wellaligned.
Provide the installation space as shown in Figure D.
