Daikin RN60CXV1 - Page 5

1-3
English
KLL
A
M
B
I
G
N
O
P
RS
J
C
Q
H
D
EF
Outdoor Unit (RN/RYN)
N
L
KL
QN
M
A
DO
BP
RS
C
HG
E
IJ
F
Outdoor Unit (RN/RR/RYN/RQ)
N
All dimensions are in mm
All dimensions are in mm
Dimension
Model
ABCDEFGHIJKLMNOPQRS
25/35C 700 521 250 478 175 36 95 94 86 68 440 130 110 15 21 19 278 80 65
Dimension
Model
ABCDEFGHI JKL
50C 855 628 328 520 179 46 93 149 101 113 603 126
60/71C 855 730 328 520 179 46 93 149 101 113 603 126
Dimension
Model
MNO PQR S
50C 164 15 34 23 362 73 75
60/71C 164 15 34 23 362 73 75
