Daikin RN60CXV1 - Installation Diagram; Indoor Unit; Outdoor Unit

1-7
English
INSTALLATION DIAGRAM
Indoor unit
Supply Duct
Air Intake
Wrap the insulated pipe with the
finishing tape from bottom to top
Air Intake
Return Duct
Hanger
Air Discharge
Drain Piping
Thermal Insulation
Outdoor unit
