Daikin RXS35L2V1B Installation Manual

11 English
Wiring diagram
Wiring diagram parts table
: Terminal strip : Field wiring
: Connector : Relay connector
: Connection : Terminal
BLK : Black ORG : Orange
BLU : Blue RED : Red
BRN : Brown WHT : White
GRN : Green YLW : Yellow
Notes
: Refer to the nameplate of the unit for power requirements.
: TO INDOOR UNIT To indoor unit
: POWER SUPPLY Power supply
: IN CASE OF COOLING ONLY TYPE In case of cooling only type
: OUTDOOR Outdoor
: CONDENSER Condenser
: DISCHARGE Discharge
C7,C8..................... Capacitor
DB1,DB3................ Diode bridge
FU1,FU2,FU3 ........ Fuse
FU4 ........................ Field fuse
IPM ........................ Intelligent power module
L............................. Live
L803,L804.............. Reactor
M1C ....................... Compressor motor
M1F........................ Fan motor
MRCW,MRM10,
MRM20,MR30........ Magnetic relay
N ............................ Neutral
Q1L ........................ Overload protector
Q1DI ...................... Earth leak detector
PCB1,PCB2 ...........Printed circuit board
S10,S11,S12,S20,
S40,S70,S80,S90,
HL3,HN3,X11A.......Connector
R1T,R2T,R3T .........Thermistor
SA1 ........................Surge absorber
V1,V2,V3................Varistor
X1M........................Terminal strip
Y1E ........................Electronic expansion valve coil
Y1S ........................Reversing solenoid valve
Z1C~Z4C ...............Noise filter (ferrite core)
........................Protective earth
........................Earth
