INSTALLATION
MANUAL
R410A Split Series
Models
RXS20CVMB RKS20CVMB
RXS25CVMB RKS25CVMB
RXS35CVMB RKS35CVMB
ARXS20CVMB ARKS20CVMB
ARXS25CVMB ARKS25CVMB
ARXS35CVMB ARKS35CVMB
RXS20C2VMB RKS20C2VMB
RXS25C2VMB RKS25C2VMB
RXS35C2VMB RKS35C2VMB
ARXS20C2VMB ARKS20C2VMB
ARXS25C2VMB ARKS25C2VMB
ARXS35C2VMB ARKS35C2VMB
RXG25CVMB RXG25E2V1B
RXG35CVMB RXG35E2V1B
ARXG25CVMB ARXG25E2V1B
ARXG35CVMB ARXG35E2V1B
Deutsch
Français
Nederlands
Español
Italiano
ΕλληνικÜ
Portugues
Рóссêий
English
Türkçe
Installation manual
R410A Split series
Montaj kýlavuzlarý
R410A Split serisi
Installationsanleitung
Split-Baureihe R410A
Manuel d’installation
Série split R410A
Montagehandleiding
R410A Split-systeem
Manual de instalación
Serie Split R410A
Manuale d’installazione
Serie Multiambienti R410A
Εγχειρßδιο εγκατÜστασηò
διαιροýìενηò σειρÜò R410A
Manual de Instalação
Série split R410A
Рóêоводство по монтажó
Серия R410A с раздельной óстановêой
