SiUS281811EA Field Settings from Outdoor Unit
Part 5 Field Settings and Test Operation 177
Note(s)
2.5 Monitor Mode
Various Settings
Press the SET (BS2) button and match with the LEDs No. 1 - 15, push the RETURN (BS3) button,
and confirm the data for each setting.
The numbers in the No. column represent the number of times to press the SET
(BS2) button.
No. Setting item
LED display
Data display
H1P H2P H3P H4P H5P H6P H7P
0 Various setting
lhhhhhh
See the note below.
1 Cool / heat unified address
lhhhhhk
Lower 6 digits
2 Low noise / demand address
lhhhhkh
3Not used
lhhhhkk
4AIRNET address
lhhhkhh
5 Number of connected indoor units
lhhhkhk
7
Number of connected zone units
(excluding outdoor and BS unit)
lhhhkkk
8 Number of outdoor units
lhhkhhh
11
Number of zone units (excluding
outdoor and BS unit)
lhhkhkk
Lower 6 digits
12 Number of terminal blocks
lhhkkhh
Lower 4 digits:
upper
13 Number of terminal blocks
lhhkkhk
Lower 4 digits: lower
14 Error description (the latest)
lhhkkkh
Refer to the
error code table
on Part 6.
15
Error description
(1 cycle before)
lhhkkkk
16
Error description
(2 cycle before)
lhkhhhh
20 Contents of retry (the latest)
lhkhkhh
21 Contents of retry (1 cycle before)
lhkhkhk
22 Contents of retry (2 cycle before)
lhkhkkh
25
Normal judgment of outdoor units
PCB
lhkkhhk
Lower2 digits:
kh Abnormal
hk Normal
hh
Unjudgment
Selection of check item
Confirmation on check item
Press the MODE (BS1) button and
enter the monitor mode.
Press the SET (BS2) button and
select a check item according to the
LED pattern.
Press the RETURN (BS3) button to
display different data of check item.
Press the RETURN (BS3) button
and return to the initial status of
monitor mode.
∗ If you become unsure of how to
proceed, press the MODE (BS1)
button and return to the setting
mode 1.
H1P H2P H3P H4P H5P H6P H7P
Emergency operation /
backup operation setting
ON lhhkhhh
OFF lhhhhhh
Defrost select setting Short lhhhkhh
Medium lhhhlhh
Long lhhhhhh
Te setting H lhhhhkh
M lhhhhlh
L lhhhhhh
Tc setting H lhhhhhk
M lhhhhhl
L lhhhhhh
