Daikin UWL030B5 - Electrical Data; Safety Devices

7
Electrical Data
Safety Devices
Model UWL030B5 UWL040B5
Compressor
Rated running
current
A 18.3X3 18.3X4
IP/ Insulation grade IPX4/E IPX4/E
Unit operating current A 38.7 50.4
Unit max running current A 74 95
Unit max power input kW 40.5 51.8
Notes:
1. Allspecictionsaresubjectedtochangebythemanufacturerwithoutpriornotice.
2. Maxrunningcurrentistestedunderbelowcondition:EWTofusingsideis30ºC,
EWTofheatsourcesideis50ºC.
Notes:
1. Allspecictionsaresubjectedtochangebythemanufacturerwithoutpriornotice.
Model UWL030B5 UWL040B5
Safetydevice
Highpressure
switch
Type
PSW,H20PSB PSW,H20PSB
Open MPa 4.15 ± 0.1 4.15 ± 0.1
Close MPa 3.11 ± 0.1 3.11 ± 0.1
Low pressure
switch
Type N/A N/A
Open MPa N/A N/A
Close MPa N/A N/A
Phasesequencer YES YES
Dischargetemperature
setting
°C/°F 130/266 130/266
