Field Setting on Outdoor Unit Si30-408
62 Field Settings from Remote Controller
While pressing the button, press the button when No. 1 to No. 15 LED meets the
target, thus making it possible to check respective data.
Data expresses addresses or the number of units in binary numbers and
has two expression methods.
For example, the cool/heat unified address of No. 1 LED is expressed in
binary number of lower six digits. (0 to 63)
In the case of , the address becomes 010110 (in binary number), which
translates to 16 + 4 + 2 = 22 (in decimal number). As a result, the address
becomes 22.
For example, the number of terminal units for Nos. 12 and 13 is expressed
in eight-digit binary number, which are the combination of four upper and
four lower digits for Nos. 12 and 13 respectively. (0 to 128)
In the case of , the addresses for No. 12 and No. 13 become 0101 and
0110 respectively and the combination of the two addresses becomes
01010110 (in binary number), which translates to 64 + 16 + 4 + 2 = 86 (in
decimal number). As a result, the number of terminal units becomes 86.
For data name and others of No. 1 to No. 22, refer to information listed in table on the preceding page.
SET
RETURN
9 797997
16 4 1
32 8 2
Q
977 7979
64 16
128 32
No.12
977 7997
4 1
No.13
8 2
R
To Next Page
