Installation and Maintenance
Service Manual
NO.
Description
Part Code
Qty
DS-18KIDB DS-21KIDB
Product Code
1 Front Panel
20000300003101T 20000300003101T 1
2 Display Board
300001000037 300001000037 1
3 Filter Sub-Assy
11122089 11122089 1
4 Front Case
20000200000801 20000200000801 1
5 Guide Louver
20000400000401 20000400000401 1
6 Axile Bush
10542036 10542036 2
7 Air Louver
10512732 10512732 3
8 Helicoid Tongue
26112512 26112512 1
9 Left Axile Bush
10512037 10512037 1
10 Rear Case assy
000001000009 000001000009 1
11 Rubber Plug (Water Tray)
76712012 76712012 1
12 O-Gasket of Cross Fan Bearing
76512203 76512203 1
13 Ring of Bearing
26152025 26152025 1
14 Evaporator Support
24212177 24212177 1
15 Evaporator Assy
011001000207 01002000003 1
16 Cross Flow Fan
10352060 10352060 1
17 Fan Motor
1501214502 1501214502 1
18 Motor Press Plate
26112511 26112511 1
19 Wall Mounting Frame
01362026 01362026 1
20 Connecting pipe clamp
2611218801 2611218801 1
21 Crank
73012005 73012005 1
22 Stepping Motor
1521240210 1521240210 1
23 Drainage Hose
05230014 05230014 1
24 Electric Box Assy
100002001422 100002001355 1
25 Lower Shield of Electric Box
01592139 01592139 1
26 Electric Box
20112211 20112211 1
27 Jumper
4202021912 4202021912 1
28 Main Board
300002000397 300002000397 1
29 Shield Cover of Electric Box
01592176 01592176 1
30 Electric Box Cover
20112209 20112209 1
31 Terminal Board
42011233 42011233 1
32 Screw Cover
242520179 242520179 3
33 Electric Box Cover2
20112210 20112210 1
34 Power Cord
/ / /
35 Connecting Cable
/ / /
36 Connecting Cable
4002052317 4002052317 0
37 Remote Controller
305001000009 305001000009 1
38 Detecting plate(WIFI)
30110144 30110144 1
Above data is subject to change without notice.
