84
Installation and Maintenance
Service Manual
Procedure
Step
4.Remove cabinet
Screw
Screw
Screw
Remove the screws xing right side plate
and then remove the right side plate.
5.Remove right side plate and rear grill
Screw
Screw
Cabinet
Right side plate
Rear grill
Remove the screws xing cabinet and then
remove the cabinet.
Remove the screws and then remove the
grille.
