Dali DT8 - Operation and Group Setting; Setting Group Number via Rotary Switch

1. Do wiring according to connection diagram correctly.
2. Set starting Group number via rotary switch on the back: (0-15 selectable)
• This DALI push button controller enables dimming commands and DT8 commands to be sent to One Group of
devices on the DALI circuit. A rotary switch on the back is used to select the DALI Group you would like to
control and set the starting Group number, and total 16 Groups (0-15) can be selected.
• When the rotary switch arrow position is at 0, the controller controls all devices on DALI circuit through
broadcast.
• When the rotary switch arrow position is at X except 0 (1-15), the controller controls devices in Group X-1.
For example: Rotary switch arrow at 1, the controller controls devices in Group 0. Rotary switch arrow at 15, the
controller controls devices in Group 14.
Please refer to the detailed Group setting table as follows:
Rotary Switch
Position
DALI Group
Selected
0
Broadcast
1
0
2
1
3
2
4
3
5
4
6
5
7
6
8
7
9
8
10
9
11
10
12
11
13
12
14
13
15
14
Operation
Note: please assign the devices on DALI circuit to a DALI group(0-15) with DALI master controller first.
