Dali EPIKORE 11 - Page 6

C
B
B
A
B
B
A
D
C
C
4
Place a spike outrigger
A
in position on the boom panel of the EPIKORE11 and use its aachment screws
B
and
the 5mm Allen key
C
to secure it in position. Tighten the screws fully.
Repeat for all four spike outriggers.
5
Remove the accessory box.
A
Remove the top halves of the centre packing blocks
B
, and the two packing end caps
C
to leave the EPIKORE11
supported by the remaining centre packing blocks. Open the cabinet protection cloth in the boom of the
loudspeaker
D
.
5mm
Do not overtighten.
DALI EPIKORE Manual6
