Dali EPIKORE 11 - Page 8

B
A
A
A
5mm
B
10
9
0-5 mm
Screw a lock nut thumbscrew
A
by hand to the top of each Spike.
Remove the EPIKORE11 tweeter dome protector
B
.
Carefully tilt the EPIKORE11 to the side with the
magnetic spike protectors aached, so that the
floor protection pads can be removed.
If the magnetic spike protectors are to be used,
apply the two remaining spike protectors under
the spikes on one side while the loudspeaker is
tilted. If the spike protectors are not to be used,
remove the previously applied spike protectors
by carefully tilting the speaker to the other side.
Adjust the spikes
A
so that the loudspeaker is
stable using the 5mm Allen key.
B
Do not overtighten.
DALI EPIKORE Manual8
