1
2
43 21
FIGURE 3A FIGURE 3B FIGURE 4
FIGURE 5 FIGURE 6A FIGURE 6B
FIGURE 7A FIGURE 7B FIGURE 7C
FAZON MIKRO FAZON MIKRO VOKAL
Frequency Range [+/- 3] dB [Hz] 95-25.000 95-25.000
Sensitivity [2.83V/1m] [dB] 84.0 84.0
Nominal Impedance [ohms] 6 6
Maximum SPL [dB] 101 101
Recommended Amp. Power [Watts] 30-120 30-120
Crossover Frequencies [Hz] 2.560 2.560
High Frequency Driver 1 x 20 mm soft fibre dome 1 x 20 mm soft fibre dome
Low Frequency/Midrange Driver(s) 1 x 4” wood fibre cone 1 x 4” wood fibre cone
Enclosure Type Closed box Closed box
Connection Input(s) Single wire Single wire
Recommended Placement Above/Below TV Screen, On-Wall,
Shelf, Stand
Above/Below TV Screen, On-Wall,
Shelf, Stand
Magnetic Shielding No No
Dimensions (H x W x D) [mm]
(Wall mounted)
196 x 113 x 96 113 x 196 x 96
Dimensions (H x W x D) [inches]
(Wall mounted)
7.72 x 4.45 x 3.78 4.45 x 7.72 x 3.78
Dimensions (H x W x D) [mm]
(Placed on a desk)
196 x 113 x 99 115 x 196 x 99
Dimensions (H x W x D) [inches]
(Placed on a desk)
7.72 x 4.45 x 3.90 4.53 x 7.72 x 3.90
Weight [kg/lb] 1.5/3.3 1.5/3.3
Accessories Wall bracket
Wall bracket bumper
Pads
Manual
Wall bracket
Wall bracket bumper
Pads
Manual
TABLE 2 - FAZON MIKRO TECHNICAL SPECIFICATIONS
All technical specifications are subject to change without notice.
FIGURE 8A FIGURE 8B
FIGURE 9
