12
10. AMPLIFIER BACK PLATE (FIGURE 3)
A) ON/STANDBY LED, indicator is green when POWER is set to ON or when an input signal is
detected. The LED is red, if the subwoofer is in standby mode.
B) VOLUME adjustment: Turn the button towards “Max” to increase the sound level. To reduce
the sound level, turn the button towards “Min”.
C) CROSSOVER: Adjustment of the crossover frequency from 50 Hz to 130 Hz.
D) Toggle the phase of the subwoofer to either 0 degrees or 180 degrees phase angle.
E) LINE input: Connect the “L” input connector (white) to the LEFT RCA line output connector
of your stereo/surround sound (pre-) amplifier. Connect the “R” input connector (red) to the
RIGHT RCA line output connector of your stereo/surround sound (pre-) amplifier.
F) LFE input: Connect the “LFE” input connector (red) to the LFE RCA line output of your
surround sound amplifier.
G) POWER switch: Set the switch to ON to power up the subwoofer. Set the switch to OFF to
power off the subwoofer.
H) FUSE compartment: If the subwoofer fails to power up when connected to the mains and
the POWER switch is set to ON, the fuse may have blown or be faulty. Replace the fuse with
the same type as originally supplied – see fuse type on the amplifier back plate. If the fuse
blows repeatedly, have the subwoofer checked at an authorised service centre – contact
your authorised dealer.
I) MAINS connector: Connect the supplied power cord to the MAINS connector and your
mains outlet.
• WARNING: MAKE SURE THAT CORRECT VOLTAGE IS SUPPLIED FROM YOUR MAINS
OUTLET BEFORE CONNECTION.
J) There are three settings for the POWER MODE switch: ON: The power to the subwoofer
will be controlled by the POWER switch. AUTO: When the main power switch is on, the
subwoofer amplifier will turn on when an input signal is detected on one of the inputs. When
a signal is not detected for approximately 20 minutes, the subwoofer amplifier will go into
standby-mode. OFF: The subwoofer will immediately go into standby mode.
11.0 TECHNICAL SPECIFICATIONS
In table 2 you will find the most common specifications for our subwoofers. Please have in mind
that there are countless methods for measuring subwoofers. Only your ears can decide whether
one sub sounds better than another. Like all our speakers, DALI IKON SUB MK2 is designed to
reproduce music as honestly as possible.
Enjoy your new DALI IKON SUB MK2!
