Dali MENTOR - Page 2

INPUT
LFE
RIGHT
Designed and engineered in Denmark by DALI A/S
POWER
ON
OFF
220-240V~ 450W 50/60Hz
T
RISK OF FIRE
REPLACE FUSE AS MARKED
T2.5AL/250V
Danish Audiophile Loudspeaker Industries
CROSSOVER
POWER MODE
FOR INDOOR USE ONLY
CAUTION
WARNING: SHOCK HAZARD - DO NOT OPEN
AVIS: RISQUE DE CHOC ELECTRIQUE - NE PAS OUVRIR
CAUTION
DISCONNECT SUPPLY CORD BEFORE REPLACING FUSE.
FOR CONTINUED PROTECTION AGAINST RISK OF FIRE
REPLACE ONLY WITH SAME TYPE FUSE.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
VOLUMEPHASE
+
AUTO
MANUAL
LEFT
43
FIGURE 5 FIGURE 6 FIGURE 7
FIGURE 2 FIGURE 3 FIGURE 4
TABLE 2 - MENTOR SERIES TECHNICAL SPECIFICATIONS
37
All technical specifications are subject to change without notice.
FIGURE 8 FIGURE 9 FIGURE 10
Spike
Contra nut
Foundation
Bumper
+
_
VOLFREQ PHASE
MENTOR SUB IR REMOTE CONTROL
MEMORIES
1 32
FIGURE 11
FIGURE 12
1
2
3
4
5
6
7
8
A
B
C
D
E
F
FIGURE 13
FIGURE 14
G
MENUET 1 2 5 6 8 LCR VOKAL SUB
Frequency Range (+/-3dB)
[Hz]
68 -
25.000
45 -
34.000
39 -
34.000
43 -
34.000
36 -
34.000
34 -
34.000
45 -
34.000
39 -
34.000
25-250
Crossover Frequency [Hz] 3.000 3.400 /
12.000
3.400 /
12.000
3.000 /
12.000
800 / 3.000
/ 12.000
750 / 3.000
/ 12.000
3.000 /
12.000
2.500 /
12.000
40-120
Input Impedance [kohm] - - - - - - - - 20
Sensitivity (2.83V/1m) [dB] 86.0 86.0 86.5 88.0 89.5 90.0 86.0 90.5 -
Nominal Impedance [ohm] 4 6 6 6 6 6 6 6 -
Maximum Power
Consumption [Watt]
- - - - - - - - 450
Idle Power Consumption
[Watt]
- - - - - - - - 14
Max. Amplifier Power
Output [Watt RMS]
- - - - - - - - 500
Cont. IEC Amplifier Power
Output [Watt RMS]
- - - - - - - - 300
Maximum SPL [dB] 105 106 108 109 111 113 106 111 111
Recommended Amplifier
Power [Watt]
20 - 100 40-120 40-180 40-180 40-200 40-250 20-120 40-200 -
High Frequency Drivers
[mm]
1 x 28
soft dome
1 x 28
soft dome
1 x 17 x 45
ribbon
do do do do do do -
Midrange Drivers - - - - - 1 x 6½” - - -
Low Frequency Drivers 1 x 4½ 1 x 5” 1 x 6½” 2 x 5” 2 x 6½” 2 x 8” 1 x 5” 2 x 6½” 1x10”
Enclosure type Bass Reflex Bass reflex Bass reflex Bass reflex Bass reflex Bass reflex Bass reflex Bass reflex Closed
Connection Input Single-
wire
Single-
wire
Bi-wire Bi-wire Bi-wire Bi-wire Single-
wire
Bi-wire Mono
Line Level
(LFE).
Stereo
Line Level
(Low Pass
Filtered)
Recommended placement Shelf /
on-wall /
stand
Shelf /
on-wall /
stand
Stand Floor Floor Floor On-wall /
above /
below
screen
Below
screen
Floor
Dimensions (H x W x D)
[mm]
250 x 150
x 230
320 x 160
x 240
440 x 200
x 350
880 x 160
x 250
1030 x
200 x 390
1100 x
250 x 440
660 x 165
x 150
210 x 895
x 295
365 x 330
x 340
Dimensions (H x W x D)
[inches]
9.8 x 5.9
x 9.0
12.5 x 6.4
x 9.5
17.3 x 7.9 x
13.8
34.6 x 6.4
x 9.9
40.6 x 7.7 x
15.4
43.3 x 9.8 x
17.3
26.0 x 6.5
x 5.9
8.3 x 35.2 x
11.6
14.4 x 13.0
x 13.4
Weight [kg/lb] 4.0/8.2 5.2/11.4 10.0/22.0 14.0/30.8 22.2/48.9 35.4/78.0 6.2/13.7 17.6/38.8 22.4/49.4
