Dali SUB E-12 F - Page 38

DALI SUB E-12F
Frequency Range [+/- 3] dB [Hz] 28 - 190
Input Impedance [kohm] 25
Maximum SPL [dB] 112
Crossover Frequencies [Hz] 40 - 120
Low Frequency Driver(s) 1 x 12” long stroke
Enclosure Type Bass reflex
Bass Reflex Tuning Frequency [Hz] 36.0
Connection Input(s) RCA, Stereo (low-pass filtered) LFE (Mono)
Recommended Placement Floor, near wall or corner
Magnetic Shielding No
Max. Amplifier Power Output [RMS Watts] 220
Continous IEC Power Output [RMS Watts] 170
Max. Power Consumption [Watts] 250
Dimensions (H x W x D) [mm] 370 x 340 x 380
Dimensions (H x W x D) [inches] 14.6 x 13.4 x 15.0
Weight [kg/lb] 15.3/33.7
TABLE 2 - DALI SUB E-12F TECHNICAL SPECIFICATIONS
39
All technical specifications are subject to change without notice.
