4
OPERATION WITH THE REMOTE CONTROL
• The air conditioner will not operate if curtains, doors or other materials block the signal from the remote
control to the indoor appliance.
• Do not expose the remote control to water, direct sunlight or excessive heat.
• Do not allow direct sunlight to fall on the infrared receiver on the indoor appliance as this can impede
the signal from the remote control.
• Remote signal reception is confi rmed with a beep.
Remote Control Specifi cations
Model RG57B/BGEU1
Rated Voltage 3.0V (dry batteries R03/LR03x2)
Signal Receiving Range 8m (26 feet)
Environment -5°C to 60°C (23°F to 140°F)
MODE: Selects mode operation in
the following order:
Auto --> Cool --> Dry --> Heat --> Fan
FAN: Selects fan speed in the
following order:
Auto --> Low --> Med --> High
ON/OFF: Turns the appliance
on or off
SLEEP: Conserves energy
during sleeping hours
TURBO: Starts and stops the
turbo function, which will run
the appliance continuously to
reach the preset temperature in
the shortest amount of time; after
running for 30 minutes turbo
mode will stop
LED: Turns the LED
display on or off
TIMER OFF: Used to set
automatic off function
TIMER ON: Used to set
automatic on function
UP AND DOWN BUTTONS:
Used to increase or decrease
the temperature setting in 1°
increments. Press and hold
the up and down buttons for
three seconds to change the
temperature scale between °C
and °F
DIRECT: Used to change
the louver movement and
set the up or down air fl ow
direction
SWING: Used to start or
stop the horizontal louver
swing feature
SHORTCUT: Used to restore
the current settings or resume
previous settings
OPERATING INSTRUCTIONS
Symbol will fl ash
to indicate that the
appliance has received
the signal from the
remote control.
