SPECIFICATION
MODEL DDW1802 and DDW1805
ELECTRICAL
Rating 120V 60Hz
Motor (HP) 1/5
Motor (Amps)
Heater Wattage 1000W
Wash
Total Amps (Load Rated) 9.2A
Thermostat Contacts
Close at
127°F ±5°F
58±3
WATER SUPPLY
Suggested Min. Incoming Water
Temperature
120
°F
to 150
°F
49
to 66
Pressure (PSI) Minimum/Maximum 15/120 PSI
Connection (NPT) 3/8”
Consumption (Toil Gallons) 3.5±5%
Water Valve Flow Rate (GPM) 1.08GPM±10%
