Beer Keg Installation Instructions
CASTOR BRAKE GUIDE
STEP ON TO BRAKE
STEP ON TO RELEASE
BRAKE
INSTALLATION OF CO2
CYLINDER SUPPORT
• Install the metal support provided onto the 4 studs located on the exterior
back wall. Align the holes in the support with the studs and push down
firmly. (See Figure 1)
Figure 1 Figure 2 Figure 3
INSTALLATION OF CO2
CYLINDER
• The CO2 Cylinder does not come filled. The cylinder must be filled with
CO2 prior to use.
• Install your fully charged cylinder into the support stand.
INSTALLATION OF CO2
REGULATOR
• Attach the CO2 regulator to the cylinder by turning the regulator nut onto
cylinder valve, making sure washer is securely inserted into connecting
nut. Tighten snug using an adjustable wrench (not supplied) and assure
there are no leaks. (See Figure 2)
INSTALLATION OF CO2
AIR LINE OUTSIDE
CABINET
• Remove plug located at the exterior back (top left hand corner).
• Save it for later use if you decide to convert unit to a refrigerator.
• Insert the open end of the air line (red) line the cabinet through the
uncovered hole. (See Figure 4)
8
