PART IDENTIFICATION
ACCESSORIES
Check to ensure that all accessories are included in the package (Fig. A). Please refer to
installation for their usage
Description Quantity
1) Intake / Exhaust Hose (with collars) 2 / set
2) Wall Intake / Exhaust Adapter A 2 / set
3) Window Intake / Exhaust Adapter B 2 / set
4) Expansion plug & screws 4 / each
5) Window / Patio Slider Kit 1 / set
from 67.5cm (26
1
/2 “) up to 210cm ( 82
1
/2”)
6) Foam Seal 3 pcs
7) Remote Control 1 pc
8) Batteries 1 / set
1
2
3
4
5
6
7
8
Fig. A
UNIT PARTS
IDENTIFIED
FRONT
1) Control Panel
2) Louver Adjustment Handle
3) Vertical Louver Blades
4) Horizontal Louver Blades
5) Carrying Handles (both sides)
6) Castors (4)
1
2
3
4
5
6
Fig. B
REAR
1) Air Filter
2) Air Inlet
3) Air Outlet
4) Upper Drain Outlet
5) Vent Control
6) Power Cord Hooks
7) Lower Drain Outlet
CLOSE
OPEN
1
2
3
4
5
6
7
Fig. C
