DANCAR ELFOOT - Installation

Legs of the
caravan
Fig. M1 Fig. M2
Edge of the
spindelbolt
Adaptor
Fig. M3 Fig. M4
Fig. M5 Fig. M6
A
The two drip-stop must be
pushed to end of the cables
in oppersite direction as show.
Site 4/8
Copyright: www.dancar.dk
A
Do not tighten
Notice: The illustration show a standard leg. In market there might
be types not suitable for the Elfoot adaptor. The standard adaptor
can be modified as shown on page no. 6
shims
Important:
Installation
Spring slot
