DANDO TERRIER 2002 ROTARY HYDRAULIC ATTACHMENT
7 : 1 REDUCTION GEARBOX - PART NUMBER: ST09763X476
EX-1023
ITEM PART NUMBER QTY DESCRIPTION
1 1 Oil Seal Support
2 6 Screw
3 1 O-Ring
4 1 Output Shaft
5 2 Key
6 1 Key
7 1 Oil Seal
8 2 Bearing
9 1 Output Support
10 1 Air Escape Plug
11 2 Oil Level Plug
12 1 Magnetic Plug
13 2 Steel Plug
14 1 Ring Nut Washer
15 1 Washer
16 4 O-Ring
17 1 Planetary Ring
18 8 Screw
19 8 Spring Pin
20 1 Complete Reduction R=7/1
21 1 Shimming
22 1 Pinion R=7/1
23 1 Circlip ( Only On R=7/1)
