Dando TERRIER Mk 1 - 4. DRIVING - CONTROL POSITION

15
4. 4. DRIVING - CONTROL POSITION
4.1. MACHINE CONTROLS
1
– RIGHT TRACK LEVER
2 – LEFT TRACK LEVER
3 – SPEED SELECTOR LEVER
4 – HYDRAULIC CYLINDER CONTROL LEVER
5 – HYDRAULIC OPTIONAL TOOL CONTROL LEVER
6 – ACCELERATOR LEVER
7 – P.T.O. SWITCH
8 – DRIVING HANDLEBAR
To operate the various commands, follow the indications reported below:
9
1
2
3
4
5
6
7
8
