4.3. SERVICES
Lever “4”: dumping cylinder control
This lever controls the dumping cylinder opening / closing. To open the cylinder, push the
lever forward; to close it, just pull the lever back.
Lever “5”: ”: hydraulic optional tool control
This lever controls another section of the main valve to operate another tool.
Lever “6”: accelerator.
When the engine is started up, this lever must be at the midpoint.
WARNING!
Use the levers carefully to avoid endangering surrounding people and property.
To ensure good machine performance for a long time, never use excessive force on the
transmission and never overload the endothermic engine.
6
