5.4. PUMPS MAINTENANCE
In order to do the maintenance on the pumps it is necessary, after lifting the skip, to loose
the screws V and remove the protection panel of the pumps.
After finished the necessary maintenance, locate again the panel and tie the screws
placing the pieces as shown in below left picture.
5.5. LUBRICANT TABLE
Agip
RECOMMENDED
PRODUCTS
PARTS TO BE
LUBRICATED
QUANTITY
(Liters)
AGIP SUPERMOTOROIL
15W/40
DIESEL ENGINE See engine manual
AGIP ARNICA 46 HYDRAULIC SYSTEM 20,7 lt
AGIP GR SM GREASE POINTS As needed
It is possible to replace the suggested products with other brands as long as they have the
same characteristics.
5.6. DIESEL ENGINE
For operation, refuelling, start-up and shutdown,
controls and cleaning, and for maintenance, follow
the indications given in the User’s Manual that the
Manufacturer has supplied with the machine.
DIESEL
V
