SECTION 2 – TECHNICAL DATA
It is imperative that the rig serial number is quoted in any correspondence or
spares requisition.
2.1 RIG SERIAL NUMBER
Stamped on a plate which is riveted to rear cross member or chassis near
side member, dependant on rig type.
2.2 GENERAL DATA
2.2.1 RIG DIMENSIONS
PERCUSSIVE MAST
Overall Height (Mast in Transit) 1.485m
Overall Height (Mast Erected) 2.888m
Overall Width (Including Stabilisers) 1.166m
Overall Length (Mast in Transit) 2.700m
Overall Length (Including Stabilisers) 2.752m
2.2m ROTARY MAST
Overall Height (Mast in Transit) 2.205m
Maximum Working Height (Mast Erected) 4.766m
Minimum Working Height (Mast Erected) 2.803m
Overall Width (Mast in Transit) 0.801m
Maximum Working Width (Including Stabilisers) 1.298m
Overall Length (Mast in Transit) 2.810m
Maximum Working Length (Mast Erected) 2.762m
2.2.2 RIG WEIGHTS
Terrier Base Assembly – No Mast 830kg
Complete Percussive Mast 372kg
Complete 1.6m Rotary Mast 265kg
Complete 2.2m Rotary Mast 359kg
2.2.3 POWER UNIT
Kubota D722-E Diesel Engine 14.0kw (18.8hp) Intermittent
12.15kw (16.3hp) Continuous
Cylinders 3
Cubic Capacity 719cc
r.p.m. 3800 Max
Tank Capacity 8.5 Litres
Endurance 5 hours
Battery 12v 36Ah
2.2.4 MAST
Pullback 7000kg
