TERRIER 2002 SAMPLING RIG
ASSEMBLY OF TERRIER 2002 SAMPLING RIG
PART NUMBER: PST/2000F200
ITEM PART
NUMBER
QTY DESCRIPTION
1 PST/2010/F200 1 Mast General Assembly
2 PST/2114/H000 2 Wheel Hub Axle
3 PST/2140/F100 1 Guard Installation
4 PST/2150/F100 1 Base Fabrication Assembly
5 PST/2153/H000 4 Staunchion
6 PST/2154/H200 6 Locking Pin
7 PST/2159/H000 1 Locking Pin
8 PST/2160/F200 1 Pivot Frame Assembly
9 PST/2168/H000 1 Pivot Pin (Ram Body)
10 PST/2169/H000 1 Pivot Ram
11 PST/2170/H100 2 Frame Pivot Pin
12 PST/2171/H100 1 Ram Rod Pin
13 PST/2172/H000 2 Body Locking Bracket
14 PST/2173/F000 1 Durbar Plate Installation
15 4 Self Locking Nut
16 3 Linch Pin
17 4 Hex Head Bolt
18 6 Hex Head Bolt
19 2 Hex Head Bolt
20 PST/2065/H000 2 Locking Pin (Mast Base Plate)
21 2 Nut
22 8 Ordinary Washer
23 4 Ordinary Washer
24 6 Spring Washer (Single Coil)
25 2 Hub c/w Bearings
26 2 Split (Cotter) Pin
27 2 Wheel Rim c/w Tyre
28 4 Soc Head Cap Screw
29 2 Hex Head Bolt
30 4 Ordinary Nut
31 PST/2196/H000 1 Modification to Handles
32 3 Hex Head Bolt
33 7 Nyloc Lock Nut
34 11 Ordinary Washer
35 1 Valve
36 1 Vice
37 PST/2192/H100 1 Body Pivot Pin
38 1 Hex Head Screw
39 1 Hex Nut
40 1 Emergency Stop Button
41 PST/2220/F000 1 Hydraulic Pipework Assembly
42 PST/2240/F000 1 Breather Hose Modification
43 PST/2242/F000 1 Header Tank Filler/Breather Mod’s
-24-
