TERRIER 2002 SAMPLING RIG
MAST GENERAL ASSEMBLY
PART NUMBER – PST2010F200
ITEM PART
NUMBER
QTY DESCRIPTION
1 PST/2011/H100 1 Light Anvil
2 PST/2012/F100 1 Heavy Anvil
3 PST/2014/H100 2 Guide Rod
4 PST/2015/H000 2 Guide Locking Plate
5 PST/2016/H000 2 Bottom Anvil Stop
6 PST/2017/H000 1 Drive Block
7 PST/2018/H000 1 Drive Block Guide
8 PST/2019/H100 1 Drive Block Cushion
9 PST/2020/H000 1 Drive Button
10 PST/2021/H000 1 Collar
11 PST/2022/H000 1 Drive Adaptor
12 PST/2023/H000 2 Stop Cushion
13 PST/2024/H100 1 Sample Tube Connector
14 PST/2025/H000 1 Idle Sprocket
15 PST/2029/H000 1 Idle Sprocket Shaft
16 PST/2030/H000 1 Motor Sprocket
17 PST/2031/H000 1 Light Anvil Adaptor Bracket
18 PST/2032/H100 1 Lifting Link
19 PST/2033/F100 1 Extraction Ram
20 PST/2034/H000 2 Link Pin
21 PST/2039/H100 1 Chain Link Cam
22 PST/2043/H000 4 Guide Bush
23 PST/2046/H100 1 Extraction Ram Rod Pin
24 PST/2047/H100 7 Anti-Vibration Mounting
25 PST/2049/H100 1 Lift Plug
26 PST/2050/F100 1 Inner Mast Fabrication Assembly
27 PST/2100/F100 1 Outer Mast Fabrication Assembly
28 PST/2054/H100 1 Pin Retaining Plate
29 1 Grub Screw
ITEMS 52, 53, 54 & 55 – NOT SHOWN.
