TERRIER 2002 SAMPLING RIG
MAST GENERAL ASSEMBLY
PART NUMBER – PST2010F200
ITEM PART
NUMBER
QTY DESCRIPTION
30
31 1 Hex Head Set Screw
32 4 Hex Head Bolt
33 2 Socket Countersunk Screw
34 2 Studding
35 4 Hex Head Set Screw
36 ST02166X133 2 Hex Head Bolt
37 ST07891X133 1 Hex Head Bolt
38 ST03357X127 3 Ball Bearing
39 ST09882X161 1 Roller Chain
40 1 Motor
41 1 Straight Rectangular Parallel Key
42 1 Thin Nut
43 2 Ordinary Nut
44 1 Thin Nut
45 1 Ordinary Washer
46 ST04295X883 4 Ordinary Washer
47
48 2 Spring Washe
49 ST00651X885 5 Spring Washer
50 2 Straight Greaser
51 1 Countersunk Screw
52 PST/2111/F200 2 Front Legs
53 PST/2112/F100 2 Back Legs
54 PST/2113/H100 4 Jack Screw
55 PST/2115/H000 4 Jack Foot Plate
ITEMS 52, 53, 54 & 55 – NOT SHOWN.
