TERRIER 2002 SAMPLING RIG
DURBAR SKID PLATE INSTALLATION
PART NUMBER – PST2173F000
ITEM PART
NUMBER
QTY DESCRIPTION
1 PST/2174/H000 1 Base Plate (Centre)
2 PST/2175/H000 1 Base Plate (L.H.)
3 PST/2176/H000 1 Base Plate (R.H.)
4 PST/2177/H000 1 Base Plate(L.H.)
5 PST/2178/H000 1 Base Plate (R.H.)
6 PST/2179/H000 1 Vice Plate
7 PST/2180/H000 2 Rear Plate
8 PST/2195/H000 1 Rear Plate (Centre)
9 Soc Head C’Sunk Screw
10 Self locking Nut
11 Ordinary Washer
-36-
