TERRIER 2002 SAMPLING RIG
PIVOT RAM ASSEMBLY
PART NUMBER – PST2169H000
ITEM PART
NUMBER
QTY DESCRIPTION
1 RPD07 1 Barrel
2 RPC005 1 Piston Rod
3 RP154 1 Piston
4 RP134 1 Head Bush
5 RP115 1 End Plug
6 RP263 2 Bush
7 RP093 2 Inlet Port
8 GHK118149 1 Rod Wiper Seal
9 TSE157118/G 1 Gland
10 TPM216153 1 Piston Seal
11 127 1 ‘O’ Ring
12 153 1 ‘O’ Ring
13 RP222 1 Lock Nut
-38-
