TERRIER 2002 SAMPLING RIG
EXTRACTION RAM ASSEMBLY
PART NUMBER – PST2033F100
ITEM PART
NUMBER
QTY DESCRIPTION
1 RPD10 1 Barrel
2 RP635 1 Piston Rod
3 RP157B 1 Piston
4 RP137B 1 Head Bush
5 RP118 1 End Plug
6 1 Special Rear Flange
7 RP094 2 Inlet Port
8 GHK157188 1 Rod Wiper Seal
9 TSE196157 1 Gland
10 TPM275196 1 Piston Seal
11 135 1 ‘O’ Ring
12 167 1 ‘O’ Ring
13 RP223 1 Lock Nut
