Wiring
• General Information
– Maximum voltage to control card is 24Vdc
– Do NOT connect 120/240/460/575 to Control
terminals
– Use Relay 01, 02, 03 for 120 or 240Vac
The maximum voltage for the control circuit must not exceed 24Vdc. A separate relay
terminal 01, 02, 03 is used for higher voltages, 120/240 Vac.
