Pre-Installation Check
Compare AFD model number with what was ordered.
Catalog Order Number System (Found on page D 62 of the catalog)
Example: VLT- 5008–P-T5-B20–EB-R0–DL-F00-A00-C0
VLT: Series
5XXX: Model Number -------------|
P: Process Application -----------------|
AC Line Voltage -----------------------------|
T2: 3 phase 200 – 240 Vac
T5: 3 phase 380 – 500 Vac
T6: 3 phase 550 – 600 Vac
Enclosure (dimensions -page 39)-------------|
B20: Bookstyle Chassis (IP20)
C00: Compact Chassis (IP 00)
C20: Compact Protected Chassis (IP 20)
CN1: Compact NEMA 1 (IP 20)
C54: Compact NEMA 12 (IP 54)
Hardware – EB
ST means Standard
SB means Standard with Brake
EB means Extended with brake (load-sharing) the 300-
500Hp have EX and DX which has a fuse disconnect
RFI Filter – R0
R0 means no extra filter
R1 adds 1A filter
R3 adds both 1A and 1B filter
Display – DL
DL means with LCP display
D0 is without the LCP
Fieldbus Option – F00
F00 = none; F10 = Profibus DP/FMS; F20 = Modbus +; F30 =
DeviceNet; F40 = LonWorks
Application Option – A00
A00 = none; A10 = Programmable Sync/Pos Card; A11 =
Synchronizing card; A12 = Positioning Card
Conformal Coating – C0
C0 means no coating
C1 has coating
