Danfoss AME 335 - DIP Switch Settings; Input Signal Type Selector; Actuator Operational Modes; Reset Mode (5 sec press)

© Danfoss | 2016.10 | 3
VI.LE.J5.3B
AME 335, AME 435
④
⑤
①
❷
①
5sec. = RESET MODE
LED: green
LED: red
①
1sec. = STAND-BY MODE - ON
STAND-BY MODE - OFF
②
③
❸ ❹
❺
ON
OFF
2 … 10 V INV SLOW LOG SMART
0 … 10 V
DIR
FAST
LIN
ACT
①
②
③
7.5 sec/mm 15 sec/mm
S [mm] T [sec] S [mm] T [sec]
10 75 10 150
15 112.5 15 225
20 150 20 300
④
③
②
