Menu selection Meaning Factory setting
INTEGRAL DELAY Delay of integral calculation in seconds after the integral value for HGW
has been reached.
10S
(range: 5S / 120S)
HGW-SHUNT TIME The time that the signal is active to open or close the HGW shunt com-
pletely.
35S
(range: 15S / 60S)
HGW INT. BOUND. Integral value (parameter) for HGW. 60
(range: 10 / 120)
HGW INTEGRAL Shows the actual value for the HGW integral. Plus indicates that the
shunt opens towards the water heater and minus indicates that the
shunt opens towards the heating system.
-
PULSE WIDTH How long the plus or minus signal to the shunt is to be high when the
HGW integral has been reached.
0.25S
(range: 0.20S / 1.00S)
62 – Installation instructions VMBMA1002
